ZDSC0606 Industrial Robot
Arc welding robots are mainly used for arc welding to achieve high quality welding by controlling the intensity and position of the arc.
Description: 4-axis high-efficiency arc welding robot, arm length 600mm, default load is 6KG, repeated positioning accuracy ±0.03mm, protection level: IP20, installation: ground installation, in order to have a good experience, we can according to the customer's common language, the machine's operating system language modification.
Four-axis high-efficiency arc welding robot with secondary development functions: inspection, handling, palletizing, assembly, polishing, cutting, painting, etc.
Polyfull provides users with a high-performance basic solution for simple and fast mastering of automated welding, with comprehensive system functions, simple and efficient programming, only need to enter the required welding current, the synergistic characteristic curve, and then automatically correspond to the setup of all the other welding parameters, and a wealth of additional functions to meet the user's higher welding requirements.
|
Robot model |
Freedom |
Load |
Arm length |
Repeatability |
|
ZDSC0606 |
4 |
6kg |
600mm |
±0.03mm |
Advantages
1. Small size, high flexibility, do not need to occupy a large area of work.
2. Can work for a long time, with the advantages of long-term welding operations, to ensure the high productivity of arc welding, high quality and high stability
3. High safety factor to protect workers' safety
4. Reduce production costs, according to most customer feedback, use within one year can recover all investment costs.
Application areas
automobiles and automotive parts, CNC machine tools arc welding, steel consumables, shipbuilding, etc.
Polyfull Intelligent Technology provides users with a high-performance basic solution for simple and fast mastering of automated welding, with comprehensive system functions, simple and efficient programming, only need to enter the required welding current, synergistic characteristic curves, and then automatically correspond to the setup of all the other welding parameters, and a wealth of additional functions to meet the user's higher welding requirements.
Service
1. The warranty period is one year,.
2. After-sales service 24 hours online answer your questions, and summarize the feedback to the technical staff.
3. Our company's engineers can provide overseas after-sales service.
